Should I choose 70% or 99% cleanroom cotton swabs？

Professional grade isopropyl alcohol cleaning tool operation guide

In the field of precision instrument maintenance, Isopropyl Alcohol (IPA) extruded clean room swabs have become the preferred tool for cleaning electronic components. This type of special cleaning consumables can effectively remove micron-scale contaminants on the surface of precision devices such as integrated circuit boards and optical lenses. Its application range covers multiple professional fields such as semiconductor manufacturing to medical equipment maintenance.

Before implementing cleaning operations in environmental preparation and safety specifications, ensure that the equipment is completely powered off and an operating environment that complies with ISO Level 5 cleanliness standards is established. It is recommended to operate on a workbench equipped with local exhaust devices, and control the ambient temperature to the golden range of 18-24℃ and relative humidity of 40-60%. Pay special attention to stay away from the heat source at least 3 meters, because the explosion limit of isopropanol vapor in the air is 2-12.7% (volume ratio).

Scientific basis for the selection of solvent concentrations. Medical grade isopropanol has two concentration specifications: 70% and 99%. After testing and verification by MIT Materials Laboratory, the 70% concentration solution contains 30% deionized water, and its surface tension is reduced by 23% compared with pure isopropanol, making it easier to penetrate microscopic pores. Taking the removal of residual after welding as an example, the pollutant removal efficiency of 70% IPA can reach 1.8 times that of 99% IPA, which is due to the fact that water molecules act as carriers to extend the solvent action time.

Operation process of professional-grade clean room cotton swabs  1. Material unsealing: Use a double-layer vacuum-packed clean room-grade cotton swab. When unpacking, the anti-static packaging bag should be torn open at a 45-degree angle.

2. Pressure control: Use the three-finger grip method to apply a uniform pressure of about 0.3N to activate the cotton swab storage chamber, and observe the solution to seep evenly along the fiber conduit

3. Cleaning method: Wipe outward from the center with a concentric circle trajectory. It is recommended to perform 5-7 reciprocating movements per square centimeter.

4. Drying management: Let stand for 120–180 seconds under laminar flow conditions to ensure the complete volatility of the solvent. If necessary, use a megascopic drying auxiliary device.

Key parameter control and precautions • Contact pressure: It is recommended to be controlled in the range of 200-400Pa. Exceeding this range may cause mechanical damage to fragile structures such as gold fingers • Wiping speed: The optimal linear speed is 15-20cm/s. Too fast will cause the solvent to be insufficient, and too slow may cause material swelling • Sweet replacement: Each standard cotton swab is recommended to clean the area not exceeding 2cm² to avoid cross contamination

For special scenario applications, it is recommended to maintain super-precision components such as hard disk read and write heads. It is recommended to use a gradient cleaning solution: first use 99% IPA to remove organic residues, and then use 70% IPA to perform final cleaning. In the maintenance of the lithography machine mirror set, low precipitation swabs made of polyethersulfone should be used, and the particle release amount is 98% lower than that of traditional swabs.
